Model

GT-AX11000

Details

Standards

IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, IPv4, IPv6

Wireless Standard

IEEE 802.11a / IEEE 802.11ac / IEEE 802.11b / IEEE 802.11g / IEEE 802.11n

Security

64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise, WPA2-Enterprise, WPS support

WPA/WPA2

WPA2

WAN Ports

1 x 10/100/1000M WAN; 4 x 10/100/1000M LAN

LAN Ports

4 x 10/100/1000M

LEDs

1 x Power
2 x Wi-Fi
1 x WAN
1 x LAN
2 x USB
1 x WPS
1 x 2.5G Port

Buttons

WPS Button, Reset Button, Power Button, Wireless on / off Button, Boost Key

Wireless Data Rates

802.11ax (2.4 GHz): up to 1148 Mbps
802.11ax (5 GHz): up to 4804 Mbps

Frequency Band

4 x 2.4 GHz
4 x 5 GHz-1
4 x 5 GHz-2

Antenna

8 x External antenna

Interface

2 x USB 3.1 Gen 1

VPN support

IPSec Pass-Through
PPTP Pass-Through
L2TP Pass-Through
PPTP server
OpenVPN server
PPTP client
L2TP client
OpenVPN client

Power Adapter

AC Input: 110V~240V (50~60 Hz)
DC Output: 19V with max. 3.42A current

System Requirements

Windows 10
Windows 8
Windows 7
Mac OS X 10.6
Mac OS X 10.7
Mac OS X 10.8

Dimensions

60.96 mm x 241.30 mm x 241.30 mm

Weight

1.72 kg

Features

Triple-level Game Acceleration - Accelerate game traffic every step of the way - from device to game server.

Battle-ready-hardware - 1.8 GHz quad-core CPU and 2.5GBase-T port for ultimate performance.

Front-line Network Security - Neutralize internet threats before they hit your network.

Better Partner with Mesh System - Compatible with ASUS AiMesh Wi-Fi system for seamless whole-home coverage.
